| Body | Alder |
| Neck | Maple |
| Fingerboard | Ebony, 22 Frets |
| Pichups | Single coil (PS-581A) x 2, Humbucking (PH-641 A) x 1 |
| Tremolo unit | Precision tremolo unit |
| Guitar controls | Volume, tone (rear pickup switch), 5 positions pickup selector |
| Preset tone/MIDI | Preset tone volume, card key, octave up key, octave down key, chromatic key, program keys (1-8) |
| MIDI out message | Program change (0-63, 0-126 with ROM card), basic channel (1-16), mode 3 (poly), mode 4 (poly), velocity, pitch bend |
| Elctronic tuner | Tuning indicator (# / b), standard pitch (440,441,442,443 Hz) |
| Inputs/outputs | Guitar out, preset tone out, MIDI out, DC 9V |
| Power | 6 AA, batteries or AC-adaptor Consumption 2W |
| Dimensions/Weight___ | 1000 x 322 x 71 mm / 4,7 kg |
| Options | RAM card RA-500 |
